1、Adjustable handlebar to meet different requirements
2、Full gear-drive transmission mode with high transmission efficiency and reliable and durable performance
3、Wet friction plate clutch engage quickly and disengage completely,with a longer work life than taper clutch
4、Water pump or sprayer can be attached with more functions like insecticide sprayer,cleaning an so on
5、Optional Oil-bath air filter better dust filtration effect to lengthen the working life of engine
|
|
KY135FC |
|
Gear shifting |
R:1 F:1,2 |
|
Transmission |
Gear |
|
Clutch |
Wet friction disc clutch |
|
Tilling depth |
≥100mm |
|
Tilling width |
1350mm |
|
Wheels |
4.00-8/4.00-10/5.00-12/6.00-12 |
|
Blades |
4 pieces, 5groups dry-land blades |
|
Engine model |
186F |
|
Rated output |
6.3/3600kW/rpm |
|
Displacement |
406ml |
|
Fuel consumption |
≤285g/(kW.h) |
|
Starting mode |
Recoil start/electric start |
|
Package mode |
Carton + hob |
|
Dimensions |
980 x 570 x 780mm |
|
Net/gross weight |
141/152kg |
|
Qty/20'GP/40'HQ |
72/144set |
